MIL-DTL-0050872D (AR)
Conformance Inspection.
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8844610
4.4.2.1
Cartridge Case
SHEET 1 OF
2
NEXT HIGHER
ASSEMBLY
8844609
PARAGRAPH
CONFORMANCE
REQUIREMENT
REFERENCE
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
CRITICAL
100%
3.2
AAIE/4.5.1
1.
Three (3) or more vent holes blocked or
missing
MAJOR
101.
One or two vent holes blocked or missing
100%
3.2
AAIE/4.5.1
102.
Hardness
Level IV
3.2
4.5.2
103.
Process control inspection of bath
3/
3.2
4.5.3
temperature for anodic coating
104.
Salt spray
1/
3.2
4.5.4
105.
Diameter of vent holes
Level IV
3.2
Gage or 4.5.7
106.
True position of largest outside diameter
Level IV
3.2
Gage
with second largest diameter
107.
True position of largest inside diameter
Level IV
3.2
Gage
with second largest diameter
108.
True position of base plug cavity with
Level IV
3.2
Gage
second largest outside diameter
109.
True position of powder charge cavity with
Level IV
3.2
Gage
base plug cavity
110.
Diameter of powder charge cavity, min
Level IV
3.2
Gage
111.
Diameter of base plug cavity
Level IV
3.2
Gage
112.
Depth of base plug cavity
Level IV
3.2
Gage
113.
Depth from base to bottom of powder
Level IV
3.2
Gage
charge cup cavity
114.
Second largest outside diameter
Level IV
3.2
Gage 2/
115.
Diameter of node
Level IV
3.2
Gage
116.
Parallelism of open end to base
Level IV
3.2
Gage
117.
Perpendicularity of base to second largest
Level IV
3.2
Gage
outside diameter
118.
Largest inside diameter
Level IV
3.2
Gage 4/
119.
Distance of flat of inside projection
Level IV
3.2
Gage
120.
Diameter of flange, max
Level IV
3.2
Gage
121.
Total length
Level IV
3.2
Gage
122.
Diameter at datum length, min
Level IV
3.2
Gage
NOTES:
1/ Sampling and rejection shall be in accordance with MIL-A-8625.
2/ If the requirement cannot be met in the free state, to "go" inside diameter plug gage may be inserted
in the cartridge case while inspecting the "go" and "no-go" for this characteristic. If used, the data shall be
annotated to note use of the "go" inside diameter plug gage.
3/ Continuous monitoring inspection.
9
