MIL-DTL-50872 Cartridge, 40 Millimeter, Hedp - M433 Loading, Assembling, And PackingThis specification covers the components, assemblies, loading and assembling for one type of 40MM, high-explosive, dual-purpose \(HEDP\) cartridge, here after referred to as Cartridge, 40 Millimeter: HEDP, M433.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22


MIL-DTL-0050872D (AR)
Conformance Inspection.
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8844612
4.4.2.3
Powder Charge Cup
SHEET 1 OF
1
NEXT HIGHER
ASSEMBLY
8844609
PARAGRAPH
CONFORMANCE
REQUIREMENT
REFERENCE
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
CRITICAL
None Defined
MAJOR
101.
Length to datum
Level IV
3.2
Gage
102.
Inside diameter
Level IV
3.2
Gage
103.
Diameter of flange, maximum
Level IV
3.2
Gage
MINOR
201.
Wall thickness
Level II
3.2
Gage
202.
Evidence of poor workmanship
Level II
3.10
Visual/4.5.28
NOTES:
