MIL-DTL-0050872D (AR)
Conformance Inspection.
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8886351
4.4.2.9
Spitback Assembly
SHEET 1 OF
1
NEXT HIGHER
ASSEMBLY
8886349
PARAGRAPH
CONFORMANCE
REQUIREMENT
REFERENCE
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
CRITICAL
None Defined
MAJOR
101.
Length from forward flange to crimped
Level IV
3.2
Gage
end
102.
Swell diameter
Level IV
3.2
Gage
103.
Depth to charge, small end
Level IV
3.2
Gage
104.
Charge above flush, small end
Level IV
3.2
Gage
MINOR
201.
Crimp not full 360°
Level II
3.2
Visual
202.
Evidence of poor workmanship
Level II
3.10
Visual/4.5.28
