MIL-DTL-0050872D (AR)
Conformance Inspection.
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8886344-1
4.4.2.11
Skirt
SHEET 1 OF
1
NEXT HIGHER
ASSEMBLY
8886375
PARAGRAPH
CONFORMANCE
REQUIREMENT
REFERENCE
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
CRITICAL
None Defined
MAJOR
101.
Distance between fuze seating surface and
Level IV
3.2
Gage
cup seating surface
102.
True position of rotating bands with
Level IV
3.2
Gage
respect to bourrelet diameter
103.
Diameter rotating band
Level IV
3.2
Gage
104.
Salt spray test
1/
3.2
4.5.4
105.
Diameter of fuze cavity
Level IV
3.2
Gage
106.
True position of fuze cavity diameter with
Level IV
3.2
Gage
respect to bourrelet diameter
107.
True position of cup cavity diameter with
Level IV
3.2
Gage
respect to bourrelet diameter.
108.
Incorrect color
Level IV
3.2
Visual
MINOR
201.
Total length
Level II
3.2
Gage
202.
Diameter rear of rotating bands
Level II
3.2
Gage
203.
Diameter of cup cavity
Level II
3.2
Gage
204.
Smallest outside diameter
Level II
3.2
Gage
205.
Diameter between rotating bands
Level II
3.2
Gage
206.
Evidence of poor workmanship
Level II
3.10
Visual/4.5.28
NOTES:
1/ Sampling and rejection shall be in accordance with MIL-C-5541.
20
