MIL-DTL-0050872D (AR)
Conformance Inspection.
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8886375
4.4.2.13
Cup and Skirt Assembly
SHEET 1 OF
1
NEXT HIGHER
ASSEMBLY
8886374
PARAGRAPH
CONFORMANCE
REQUIREMENT
REFERENCE
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
CRITICAL
1.
Cracked cup 2/
100%
3.2
AAIE/4.5.1
MAJOR
101.
Bourrelet diameter
Level IV
3.2
Gage
102.
Rotating band diameter, maximum
Level IV
3.2
Gage
103.
Runout of boattail surface with fuze cavity
Level IV
3.2
Gage
depth
Adhesive not 360°
104.
Level IV
3.2
Visual
105.
Length skirt to rear rotating band,
Level IV
3.2
Gage
maximum
106.
Air pressure test
100%
3.2
4.5.14
107.
Pushout test
80 1/
3.2
4.5.15
MINOR
201.
Evidence of poor workmanship
Level II
3.10
Visual/4.5.28
NOTES:
1/ Accept on zero (0) and reject one (1).
2/ Examination for cracked cups shall occur after air pressure test.
22
