MIL-DTL-0050872D (AR)
Conformance Inspection.
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8886354
4.4.2.7
Housing Spitback
SHEET 1 OF
1
NEXT HIGHER
ASSEMBLY
8886353
PARAGRAPH
CONFORMANCE
REQUIREMENT
REFERENCE
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
CRITICAL
None defined
MAJOR
101.
Smallest outside diameter
Level IV
3.2
Gage
102.
Second largest inside diameter
Level IV
3.2
Gage
Level IV
3.2
Gage
103.
True position of second largest inside
diameter with smallest outside diameter
including perpendicularity with flange.
104.
Diameter of counterbore
Level IV
3.2
Gage
105.
True position of counterbore with second
Level IV
3.2
Gage
largest inside diameter
106.
Distance from small end to flange
Level IV
3.2
Gage
107.
Depth of counterbore
Level IV
3.2
Gage
108.
Location small basic diameter
Level IV
3.2
Gage
109.
Location large basic diameter
Level IV
3.2
Gage
MINOR
201.
Distance from large end to front face of
Level II
3.2
Gage
flange
202.
Thickness of flange
Level II
3.2
Gage
203.
Diameter of flange
Level II
3.2
Gage
204.
Large chamfer on flange missing
Level II
3.2
Visual
205.
Body diameter
Level II
3.2
Gage
206.
Evidence of poor workmanship
Level II
3.10
Visual/4.5.28
NOTES:
16
