MIL-DTL-0050872D (AR)
Conformance Inspection.
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
9276544
4.4.2.10
Liner (One Piece)
SHEET 1 OF
1
NEXT HIGHER
ASSEMBLY
8886374
PARAGRAPH
CONFORMANCE
REQUIREMENT
REFERENCE
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
CRITICAL
None Defined
MAJOR
101.
Diameter of flange
Level IV
3.2
Gage
102.
Wall thickness
Level IV
3.2
Gage
103.
Location large basic diameter
Level IV
3.2
Gage
104.
Location small basic diameter
Level IV
3.2
Gage
105.
True position of hole small end with flange
Level IV
3.2
Gage
106.
Runout of small end with flange diameter
Level IV
3.2
Gage
MINOR
201.
Length from small end to flange
Level II
3.2
Gage
202.
Evidence of poor workmanship
Level II
3.10
Visual/4.5.28
NOTES:
19
