MIL-DTL-50872 Cartridge, 40 Millimeter, Hedp - M433 Loading, Assembling, And PackingThis specification covers the components, assemblies, loading and assembling for one type of 40MM, high-explosive, dual-purpose \(HEDP\) cartridge, here after referred to as Cartridge, 40 Millimeter: HEDP, M433.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22


MIL-DTL-0050872D (AR)
Conformance Inspection.
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8844609
Cartridge Case Loading Assembly Prior to
SHEET 1 OF
1
4.4.2.4
NEXT HIGHER
Assembling Base Plug and Primer
ASSEMBLY
8886371
PARAGRAPH
CONFORMANCE
REQUIREMENT
REFERENCE
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
CRITICAL
1.
100% 1/
3.2
AAIE/4.5.1/4.5.27
Propellant charge weight more than 25%
above or below nominal load weight
MAJOR
101.
100% 1/
3.2
AAIE/4.5.1/4.5.27
Propellant charge weight outside tolerance
range but less than 25% of nominal
MINOR
201.
Evidence of poor workmanship
Level II
3.10
Visual/4.5.28
NOTES:
1/ Any cartridge found to have a propellant weight out of tolerance but within 25% of the nominal load
weight shall be removed from the lot.
