MIL-DTL-0050872D (AR)
Conformance Inspection.
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8844610
4.4.2.1
Cartridge Case (con't)
SHEET 2 OF
2
NEXT HIGHER
ASSEMBLY
8844609
PARAGRAPH
CONFORMANCE
REQUIREMENT
REFERENCE
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
MAJOR
123.
Unconfined second largest outside
Level IV
3.2
Gage 5/
diameter
124.
Burr in vent hole
Level IV
3.2
Gage
125.
Metal defective 6/
Level IV
3.9
Visual
126.
Tensile properties
7/
3.2
4.5.6
MINOR
201.
Thickness of flange
Level II
3.2
Gage
202.
Length of base plug seating projected from
Level II
3.2
Gage
bottom of base
203.
Wall thickness, min
Level II
3.2
Gage
204.
Stamping misleading or unidentifiable
Level II
3.2
Visual
205.
Protective coating with bare spot except
Level II
3.2
Visual
anode rack marks
206.
Color incorrect
Level II
3.2
Visual
207.
Evidence of poor workmanship
Level II
3.10
Visual/4.5.28
NOTES:
4/ If the requirement cannot be met in the free state, a confining fixture may be utilized while inspecting
the "go" and "no-go" for this characteristic. If used, the data shall be annotated to note use of the fixture on
outside diameter.
5/ Case must fall freely without any force into the applicable gage.
6/ Nick, crack, dent or sharp edges which might interfere with the proper assembly or end item
performance.
7/ Six (6) specimens to be taken from each heat treat batch. Accept on zero (0) reject on one (1).
10
