MIL-DTL-0050872D (AR)
Conformance Inspection.
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
9276546
4.4.2.12
Boattail Cup
SHEET 1 OF
1
NEXT HIGHER
ASSEMBLY
8886375
PARAGRAPH
CONFORMANCE
REQUIREMENT
REFERENCE
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
CRITICAL
None Defined
MAJOR
101.
Presence of cracks, voids, pipes or
100%
3.2
4.5.12
inclusions, etc.
102.
Outside diameter, maximum
Level IV
3.2
Gage
103.
Total length
Level IV
3.2
Gage
MINOR
201.
Evidence of poor workmanship
Level II
3.10
Visual/4.5.28
