MIL-DTL-0050872D (AR)
Conformance Inspection.
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8844609
4.4.2.5
Cartridge Case Loading Assembly
SHEET 1 OF
1
NEXT HIGHER
ASSEMBLY
8886371
PARAGRAPH
CONFORMANCE
REQUIREMENT
REFERENCE
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
CRITICAL
1.
Powder charge cup missing
100%
3.2
AAIE/4.5.1 1/
2.
Primer above flush with respect to base of
100%
3.2
AAIE/4.5.1
case
MAJOR
101.
Security of crimp of base plug
32 6/
3.2
4.5.8 2/
102.
Base plug above flush
Level IV
3.2
Gage
103.
Depth to base plug, maximum
Level IV
3.2
Gage
104.
Primer above flush or more than .005
Level IV
3.2
Gage
below with respect to base plug
105.
Primer function
800
3.2
4.5.9
106.
Primer deterioration
3/
3.2
4.5.10
107.
Production control check on loaded cases
4/
3.4
4.5.11
MINOR
201.
Excessive varnish on exterior surface of
Level II
3.2
Visual
primer
202.
Marking misleading or unidentifiable 5/
Level II
3.2
Visual
203.
Evidence of poor workmanship
Level II
3.10
Visual/4.5.28
NOTES:
1/ Inspection may occur prior to assembling base plug and primer.
2/ Special build units without propellant load.
3/ Sampling and rejection shall be in accordance with MIL-P-20444.
4/ Ten (10) randomly selected from every 4 hours production from each primer loading machine.
5/ See Dwg. 8844610 for marking requirements.
6/ Accept on zero (0) and reject on (1).
14
