MIL-DTL-0050872D (AR)
Conformance Inspection.
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8844611
4.4.2.2
Base Plug
SHEET 1 OF
1
NEXT HIGHER
ASSEMBLY
8844609
PARAGRAPH
CONFORMANCE
REQUIREMENT
REFERENCE
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
CRITICAL
1.
Depth of primer cavity
100%
3.2
AAIE/4.5.1
MAJOR
101.
Process control inspection of bath
2/
3.2
4.5.3
temperature for anodic coating
102.
Salt spray
1/
3.2
4.5.4
103.
Largest outside diameter
Level IV
3.2
Gage
104.
True position of smallest outside diameter
Level IV
3.2
Gage
with largest outside diameter
105.
True position of primer cavity diameter
Level IV
3.2
Gage
with largest outside diameter
106.
Smallest outside diameter
Level IV
3.2
Gage
107.
Diameter of primer cavity
Level IV
3.2
Gage
108.
Length of primer end to shoulder including
Level IV
3.2
Gage
angle
109.
Total length
Level IV
3.2
Gage
110.
Diameter of flash hole
Level IV
3.2
Gage
Level IV
3.2
Visual
111.
Radius of intersection of primer cavity
missing
MINOR
201.
Second largest outside diameter
Level II
3.2
Gage
202.
Length from primer end to far side of
Level II
3.2
Gage
shoulder
203.
Protective coating with bare spot except
Level II
3.2
Visual
anode rack marks
204.
Finish improper
Level II
3.2
Visual
205.
Color incorrect
Level II
3.2
Visual
206.
Evidence of poor workmanship
Level II
3.10
Visual/4.5.28
NOTES:
1/ Sampling and rejection shall be in accordance with MIL-A-8625.
2/ Continuous monitoring inspection.
