MIL-DTL-0048683B (AR)
Conformance Inspection
Classification of Characteristics
PARAGRAPH
TITLE
DRAWING NUMBER
9399402
1
1
SHEET
OF
4.4.2.12
Body assembly, prior to paint
NEXT HIGHER ASSEMBLY
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
REFERENCE
CRITICAL None defined
MAJOR
101.
Parallelism, back of rotating band
Level IV
3.2
Gage
with open end
102.
Distance from open end to back of
Level IV
3.2
Gage
rotating band, max
103.
Push test of rotating band
Level III
3.2
4.5.10
104.
Profile of rotating band
Level IV
3.2
Gage
105.
Runout of indicated point of taper
Level IV
3.2
Gage
with outside larger diameter
106.
Location, large diameter on taper
Level IV
3.2
Gage
107.
Pitch diameter of thread
Level IV
3.2
Gage
108.
Minor diameter of thread
Level IV
3.2
Gage
MINOR
201.
Evidence of poor workmanship
Level II
3.9
Visual/4.5.17
