MIL-DTL-0048683B (AR)
Conformance Inspection
Classification of Characteristics
PARAGRAPH
TITLE
DRAWING NUMBER
9399396
1
1
SHEET
OF
4.4.2.11
Body
NEXT HIGHER ASSEMBLY
9399402
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
REFERENCE
CRITICAL
1.
Any perforation through the base
100%
3.2
AAIE/4.5.11
2.
Base thickness at center less than
100%
3.2
AAIE/4.5.11
0.009 inch
MAJOR
101.
Large outside diameter
Level IV
3.2
Gage
102.
Runout at indicated lengths on body
Level IV
3.2
Gage
with pitch diameter (2)
103.
Base thickness at center between
Level IV
3.2
Gage
0.009 inch and 0.013 inch and
above 0.020 inch
104.
Thickness below groove (6) in base
Level IV
3.2
Gage
MINOR
201.
Diameter of rotating band surface
Level II
3.2
Gage
(after knurling)
202.
Width of rotating band surface
Level II
3.2
Gage
203.
Total length
Level II
3.2
Gage
204.
Length of effective thread, min
Level II
3.2
Gage
205.
Evidence of poor workmanship
Level II
3.9
Visual/4.5.17
Notes:
20
