MIL-DTL-0048683B (AR)
Conformance Inspection
Classification of Characteristics
PARAGRAPH
TITLE
DRAWING NUMBER
9399392
1
1
SHEET
OF
4.4.2.1
Pin, Firing
NEXT HIGHER ASSEMBLY
9399391
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
REFERENCE
CRITICAL None defined
MAJOR
101.
Profile of firing pin point
Level IV
3.2
Gage
102.
Length, firing pin point to backside
Level IV
3.2
Gage
of shoulder
MINOR
201.
Outside diameter at backside of
Level II
3.2
Gage
shoulder
202.
Total length
Level II
3.2
Gage
203.
Evidence of poor workmanship
Level II
3.9
Visual/4.5.17
