MIL-DTL-0048683B (AR)
Conformance Inspection
Classification of Characteristics
PARAGRAPH
TITLE
DRAWING NUMBER
9399394
1
1
SHEET
OF
4.4.2.4
Ogive, M918 TP
NEXT HIGHER ASSEMBLY
9399390
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
REFERENCE
CRITICAL None defined
MAJOR
101.
Major diameter, thread
Level IV
3.2
Gage
102.
Pitch diameter, thread
Level IV
3.2
Gage
103.
Largest outside diameter
Level IV
3.2
Gage
104.
Total length
Level IV
3.2
Gage
105.
Runout, largest outside diameter to
Level IV
3.2
Gage
thread pitch diameter
106.
Runout, inside diameter to thread
Level IV
3.2
Gage
pitch diameter
107.
Larger, inside diameter
Level IV
3.2
Gage
108.
Depth to step on inside diameter
Level IV
3.2
Gage
109.
Salt spray/protective finish
4 1/
3.2
4.5.2.1
110.
Missing or improperly placed
Level IV
3.2
Visual
groove
MINOR
201.
Length, full thread
Level II
3.2
Gage
202.
Length to shoulder at thread relief
Level II
3.2
Gage
203.
Diameter of thread relief
Level II
3.2
Gage
204.
Incorrect color
Level II
3.2
Visual
205.
Wall thickness
Level II
3.2
Gage
206.
Protective finish with bare spot
Level II
3.8
Visual
exposing base metal except rack
marks
207.
Evidence of poor workmanship
Level II
3.9
Visual/4.5.17
Notes:
1/ Rejection shall be in accordance with MIL-A-8625.
