MIL-DTL-0048683B (AR)
Conformance Inspection
Classification of Characteristics
PARAGRAPH
TITLE
DRAWING NUMBER
9399390
1
1
SHEET
OF
4.4.2.7
Ogive Assembly, 40mm, M918
NEXT HIGHER ASSEMBLY
9399374
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
REFERENCE
CRITICAL
1.
Anti creep spring missing 1/
100%
3.2
AAIE/4.5.11
MAJOR
101.
Depth to firing pin point
Level IV
3.2
Gage
102.
Firing pin assembly improperly
Level IV
3.2
Visual
seated
MINOR
201.
Evidence of poor workmanship
Level II
3.9
Visual/4.5.17
Notes:
1/ Assembly shall be inspected in the inverted (open end of ogive facing down) position.
16
