MIL-DTL-48683 Cartridge, 40 Millimeter, Projectile Assembly, Tp - M918 Loading, Assembling, And PackingThis specification covers the metal parts and loading, assembling and packaging for Cartridge, 40 Millimeter, Projectile Assembly, TP - M918.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22


MIL-DTL-0048683B (AR)
Conformance Inspection
Classification of Characteristics
PARAGRAPH
TITLE
DRAWING NUMBER
9399405
1
1
SHEET
OF
4.4.2.8
Cap, Inner
NEXT HIGHER ASSEMBLY
9399407
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
REFERENCE
CRITICAL None defined
MAJOR
None defined
MINOR
201.
Length
Level II
3.2
Gage
202.
Outside diameter, max (closed end)
Level II
3.2
Gage
203.
Inside diameter, min
Level II
3.2
Gage
204.
Wall thick, min
Level II
3.2
Gage
205.
Evidence of poor workmanship
Level II
3.9
Visual/4.5.17
Notes:
17
