MIL-DTL-0045585E (AR)
Conformance Inspection
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
11691395
1
3
SHEET
OF
NEXT HIGHER
4.4.2.2
Loop, Cartridge Link
ASSEMBLY
11691393
REQUIREMENT
INSPECTION METHOD
CONFORMANCE
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA 1/
PARAGRAPH
REFERENCE
Critical
NONE DEFINED
Major
101.
Improper forming, segment
Level IV
3.2
Gage/
assembly and welding, distorted
11018351
diameter. (The finished loop shall be
capable of dropping over mandrel,
detail A, with a maximum applied
weight of two
pounds)
Level IV
3.2
Gage/
102.
Improper forming, segment
11018351
assembly and welding, distorted
width. (The finished loop shall be
capable of dropping freely of its own
weight through slot)
103.
Diameter, pivot hole
Level IV
3.2
Gage/
8440212
11017979
104.
Height, leaf spring
Level IV
3.2
Gage/
8441408
12989029
105.
Height, coupling snap groove
Level IV
3.2
Gage/
8440212
11017979
106.
True position, pivot slot
Level IV
3.2
8440212
11017979
Level IV
3.2
Gage/
107.
Location, top guide surface from
horizontal center line (min. and
8440213
max.)
11017978
108.
Location, bottom guide surface from
Level IV
3.2
Gage/
horizontal center line (min. and
8440213
max.)
11017978
