MIL-DTL-0045585E (AR)
Conformance Inspection
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
11691396
1
2
SHEET
OF
NEXT HIGHER
4.4.2.3
Link, M16A2
ASSEMBLY
11691393
REQUIREMENT
INSPECTION METHOD
CONFORMANCE
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA 1/
PARAGRAPH
REFERENCE
Critical
NONE DEFINED
Major
101.
Breakaway Force Test 2/
Level IV
3.2
4.5.11,
11017981,
11018356
102.
Stripping Force Test 2/
Level IV
3.2
4.5.12,
11017981,
11018357
103.
Uncoupling Force Test 2/ 3/
Level IV
3.2
4.5.13,
11017980,
11018357
104.
Functioning
144 4/
3.3
4.5.15
105.
Nose Fan, Butt Fan, Twist and
5/
3.2
4.5.6, 4.5.7,
Free Hinging Test
4.5.8, 4.5.9
106.
Tensile Test
5/
3.2
4.5.10,
11018116,
11018218
107.
Hardness
Level IV
3.2
4.5.4
108.
Carburization & Decarburization
7/
3.2
4.5.5
Test
109.
Cleanliness
6/
3.2
4.5.14
Minor
201.
Evidence of poor workmanship
Level II
3.4
Visual/4.5.18
Notes:
1/. Sample shall be selected from each heat treat batch except for Major 104.
2/. Same links shall be used for these tests.
3/. Coupling used for this test shall be from the same lot or lots being shipped with
the loops.
4/. Sample shall be selected randomly from entire inspection lot by local Government
representative. Accept on zero (0) and reject on one (1).
