MIL-DTL-0063092B (AR)
Ogive
9243882 / 9317511 / 9251920
5 per mold cavity
Tube
9244311
10
Delay Carrier
9243886
10
Plug Anchor
9243907
5 per mold cavity
Cartridge
9243881 / 9317509 / 9255145
25
Parachute Assembly
9243906
25
4.3.2 Inspections to be performed. The first article inspection shall be 100 %
examination of all drawing characteristics (listed and unlisted) including workmanship
requirements for the parts and assemblies listed in 4.3.1 and the tests specified in Table II herein.
4.3.3 First article rejection. If any item of the sample fails to comply with the first article
requirements, the sample shall be rejected. The Government reserves the right to terminate
inspection upon any failure of an assembly, component or test specimen to comply with any of
the requirements.
TABLE II. First article inspection
M583A1 Cartridge, Sub-Assemblies and Components
N0. OF
REQUIREMENT INSPECTION
EXAMINATION OR TEST
SAMPLE
PARAGRAPH
METHOD
UNITS
Cartridge Case (Dwg.9207989)
-Hardness
100
3.6
4.5.4
-Salt spray
10
3.2
4.5.1
-Diameter of vent holes
25 1/
3.2
Gage
-Hydrostatic
100
3.8
4.5.2
Base Plug (Dwg.8844611)
-Salt spray
10
3.2
4.5.1
Cartridge Case Loading Assembly (Dwg. 9207988)
-Security of crimp of base plug
20
3.2
4.5.6
Body, Prior to painting (Dwg.9243900)
-Salt spray
5
3.2
4.5.1
Delay Carrier (Dwg.9243886)
-Salt Spray
5
3.2
4.5.1
Illuminant Assembly (Dwg.9244310/9282351/9252412)
-Static Test
25
3.2
4.5.9
Notes:
1/ Cases especially prepared for this test shall be identified from regular cases by painting a red strip
around the open end, or any positive identification approved by the Contracting Officer.
6
