MIL-DTL-0063092B (AR)
Table III. Conformance Inspection.
CLASSIFICATION OF CHARACTERISTICS
DRAWING NUMBER
TITLE
PARAGRAPH
9243886
4.4.2.10
Delay Carrier
SHEET 1 OF 1
NEXT HIGHER ASSEMBLY
9243885
EXAMINATION OR TEST
CONFORMANCE
CLASSIFICATION
REQUIREMENT
INSPECTION METHOD
CRITERIA
PARAGRAPH
REFERENCE
Critical
None defined
Major
1/
101.
Salt Spray
3.2
4.5.1
102.
Level IV
Pitch diameter of thread
3.2
Gage
103.
Level IV
Small inside diameter
3.2
Gage
104.
Concentricity of small inside diameter
Level IV
3.2
with large inside diameter
Gage
105.
Level IV
3.2
Large inside diameter
Gage
106.
2/ and 3/
3.2
Moisture content
4.5.17.1/4.5.17.5
Minor
201.
Level II
3.2
Length to flange
Gage
202.
Concentricity of body diameter with
Level II
3.2
Gage
large inside diameter
203.
Level II
3.2
Diameter of thread undercut
Gage
204.
Level II
3.9
Evidence of poor workmanship
Visual/4.5.19
NOTES:
1/ Sampling and rejection shall be in accordance with MIL-C-5541.
2/ Major 106 will be performed at assembly level (Dwg. 9243885)
3/ Sampling shall be in accordance to section 4.5.17 and rejection shall be in accordance to applicable drawings
19
