MIL-DTL-0050863D (AR)
Conformance Inspection
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8886327
Cartridge Case Assembly,
1
1
SHEET
OF
4.4.2.1
NEXT HIGHER ASSEMBLY
Prior to Loading
12926811
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
REFERENCE
CRITICAL
1.
Closing cup missing
100%
3.2
AAIE/4.5.1
2.
Three (3) or more vent holes blocked
100%
3.2
AAIE/4.5.1
or missing
MAJOR
101.
One (1) or two (2) vent holes blocked
100%
3.2
AAIE/4.5.1
or missing
102.
Two or more closing cups 1/
100%
3.2
AAIE/
Radiography/4.5.1
MINOR
201.
Evidence of poor workmanship
Level II
3.6
Visual/4.5.20
Notes:
1/. May be inspected at higher level assembly.
9
