MIL-DTL-0050863D (AR)
Conformance Inspection
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8886327
Cartridge Case Assembly Prior to
1
1
SHEET
OF
4.4.2.2
NEXT HIGHER ASSEMBLY
Assembling Base Plug and Primer
12926811
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
REFERENCE
CRITICAL
1.
Propellant charge weight less than 75%
100%
3.2
AAIE/4.5.1/
or more than 125% of assessed weight
4.5.3
MAJOR
100%
3.2
AAIE/4.5.1/
101.
Propellant charge weight out of
drawing tolerance but within +/- 25%
4.5.3
of assessed weight
MINOR
201.
Evidence of poor workmanship
Level II
3.6
Visual/4.5.20
Notes:
10
