MIL-DTL-0050863D (AR)
Conformance Inspection
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
9287855
1
1
SHEET
OF
4.4.2.7
Body
NEXT HIGHER ASSEMBLY
9285854
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
REFERENCE
CRITICAL None defined
MAJOR
101.
Dimensional inspection of embossed
1/
3.2
4.5.15
stock
102.
Diameter between knurl
Level IV
3.2
Gage
103.
Runout of outside body diameter with
Level IV
3.2
Gage
pitch diameter of thread and front face
104.
Presence of cracks, voids, pipes or
100%
3.2
4.5.17
inclusions, etc.
MINOR
201.
Diameter of rotating band surface
Level II
3.2
Gage
(after knurling)
202.
Width of rotating band surface
Level II
3.2
Gage
203.
Radius from centerline to base of body
Level II
3.2
Gage
204.
Evidence of poor workmanship
Level II
3.6
Visual/4.5.20
Notes:
1/. Two samples, width of coil by 20 inches from each coil prior to forming body.
