MIL-DTL-0050863D (AR)
Conformance Inspection
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
12926813
1
1
SHEET
OF
4.4.2.8
Liner
NEXT HIGHER ASSEMBLY
12926814
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
REFERENCE
CRITICAL None defined
MAJOR
101.
Index angle
Level IV
3.2
Gage
102.
Wall thickness at large datum diameter
Level IV
3.2
Gage
103.
Wall thickness at small datum diameter
Level IV
3.2
Gage
104.
Wall thickness of straight portion,
Level IV
3.2
Gage
small end
105.
Location of large datum diameter
Level IV
3.2
Gage
106.
Location of small datum diameter
Level IV
3.2
Gage
107.
Concentricity of outside diameter small
Level IV
3.2
Gage
end with large outside diameter
including perpendicularity
MINOR
201.
Total length
Level II
3.2
Gage
202.
Large outside diameter, min.
Level II
3.2
Gage
203.
Evidence of poor workmanship
Level II
3.6
Visual/4.5.20
Notes:
16
