MIL-DTL-0050863D (AR)
Conformance Inspection
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
12926812
1
1
SHEET
OF
4.4.2.9
Projectile Assembly
NEXT HIGHER ASSEMBLY
12926811
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
REFERENCE
CRITICAL None defined
MAJOR
101.
True position of rotating bands with
Level IV
3.2
Gage
outside diameter of fuze
102.
Gap, min, between fuze and body
Level IV
3.2
Gage
103.
Security of fuze, prior to sealant cure
Level III
3.2
4.5.6
104.
Disassembly torque test
80 1/
3.2
4.5.7
MINOR
201.
Evidence of poor workmanship
Level II
3.6
Visual/4.5.20
Notes:
1/. Accept on zero (0) and reject on one (1)
PARAGRAPH
TITLE
DRAWING NUMBER
12926812
Projectile Assembly, prior to assembly
1
1
SHEET
OF
4.4.2.10
NEXT HIGHER ASSEMBLY
to Cartridge Case Assembly
12926811
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
REFERENCE
CRITICAL None Defined
MAJOR
101.
O-ring missing from groove
Level IV
3.2
Visual
MINOR
201.
Evidence of poor workmanship
Level II
3.6
Visual/4.5.20
Notes:
17
