MIL-DTL-0050863D (AR)
Conformance Inspection
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
9287865
1
1
SHEET
OF
4.4.2.15
Housing Spitback
NEXT HIGHER ASSEMBLY
9287864
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
REFERENCE
CRITICAL None defined
MAJOR
101.
Smallest outside diameter
Level IV
3.2
Gage
102.
Second largest inside diameter
Level IV
3.2
Gage
Level IV
3.2
Gage
103.
True position of second largest inside
diameter with smallest outside
diameter including perpendicularity
with flange
104.
Diameter of counterbore
Level IV
3.2
Gage
105.
Concentricity of counterbore with
Level IV
3.2
Gage
second largest inside diameter
106.
Distance from small end to flange
Level IV
3.2
Gage
107.
Depth of counterbore
Level IV
3.2
Gage
108.
Location small basic diameter
Level IV
3.2
Gage
109.
Location large basic diameter
Level IV
3.2
Gage
MINOR
201.
Distance from large end to front face of
Level II
3.2
Gage
flange
202.
Thickness of flange
Level II
3.2
Gage
203.
Diameter of flange
Level II
3.2
Gage
204.
Body diameter
Level II
3.2
Gage
205.
Large Chamfer on flange missing
Level II
3.2
Visual
206.
Evidence of poor workmanship
Level II
3.6
Visual/4.5.20
Notes:
21
