MIL-DTL-0050863D (AR)
Conformance Inspection
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
12944747
1
1
SHEET
OF
4.4.2.11
Fuze PIBD M549A1
NEXT HIGHER ASSEMBLY
12926812
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
REFERENCE
CRITICAL
1.
X-ray examination 1/
100%
3.3
4.5.5
MAJOR
101.
X-ray examination 2/
100%
3.3
4.5.5
102.
Pushout test of spitback assembly
80 3/
3.2
4.5.11
MINOR
201.
Evidence of poor workmanship
Level II
3.6
Visual/4.5.20
Notes:
1/. Critical Defect is defined as:
a. Setback pin protrusion short
b. Setback spring missing
c. Setback pin missing or retracted
d. Rotor assembly in armed or partially armed position
e. Spin locks not engage in rotor
f. Setback pin not blocking rotor
g. Both spin locks/spring combination missing or out of position
h. Verge/Pinion Assembly missing
2/. Major Defect is defined as:
a. Setback spring not level or leg bent.
b. Foreign material present.
c. One spin lock/spring combination missing or out of position
3/. Accept on zero (0) and reject on one (1).
18
