MIL-DTL-0060982C (AR)
Conformance Inspection
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8886332
4.4.2.2
Base Plug
SHEET 1 OF
1
NEXT HIGHER ASSEMBLY
8886327
CONFORMANCE REQUIREMENT PARAGRAPH REFERENCE
CATEGORY
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
CRITICAL
1
Depth of primer cavity
100%
3.2
Gage
MAJOR
101
Salt Fog
1/
3.7
4.5.3
102
Largest outside diameter
Level IV
3.2
Gage
103
Concentricity of smallest outside diameter
with largest outside diameter
Level IV
3.2
Gage
104
Concentricity of primer cavity diameter
with largest outside diameter
Level IV
3.2
Gage
105
Smallest outside diameter
Level IV
3.2
Gage
106
Diameter of primer cavity
Level IV
3.2
Gage
107
Location of small datum diameter
Level IV
3.2
Gage
108
Location of large datum diameter
Level IV
3.2
Gage
109
Diameter of flash hole
Level IV
3.2
Gage
110
Radius of intersection of primer cavity
missing
Level IV
3.2
Visual
111
Process control inspection of bath
2/
3.6
4.5.4
temperature for anodic coating
MINOR
201
Second largest outside diameter
Level II
3.2
Gage
202
Length from primer end to far side of
shoulder
Level II
3.2
Gage
203
Protective coating with bare spot except
anode rack marks
Level II
3.2
Visual
204
Finish improper
Level II
3.8
Visual
205
Color incorrect
Level II
3.8
Visual
3.8
Visual/4.5.8
206
Evidence of poor workmanship
Level II
NOTES:
1/ Sampling and rejection shall be in accordance with MIL-A-8625.
2/ Continuous monitoring inspection.
8
