MIL-DTL-0060982C (AR)
Conformance Inspection
CLASSIFICATION OF CHARACTERISTICS
PARAGRAPH
TITLE
DRAWING NUMBER
8886329
4.4.2.1
Case Cartridge (Cont.)
SHEET 2 OF
2
NEXT HIGHER ASSEMBLY
8886327
CONFORMANCE REQUIREMENT PARAGRAPH REFERENCE
CATEGORY
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
/ INSPECTION METHOD
124
Thickness of flange
Level IV
3.2
Gage/8827872
125
Depth of sealing tip
Level IV
3.2
Gage
126
Location of large datum diameter on node
Level IV
3.2
Gage
127
Location of vent holes
Level IV
3.2
Gage
128
Metal defective (see 6.8)
Level IV
3.3
Visual
129
Process control inspection of bath
5/
temperatures
3.2
4.5.4
130
Ultrasonic Inspection of Bar Stock
100% 4/
3.8.1
4.5.8.1
131
Thickness of anodic coating
Level IV
3.4
4.5.6/9202967
MINOR
201
Protective coating with bare spot, except
Level II
3.2
Visual
anodic rack marks
202
Color incorrect
Level II
3.8
Visual
203
Length of chamfer
Level II
3.2
Gage
204
Evidence of poor workmanship
Level II
3.8
Visual/4.5.8
NOTES:
4/ This shall be performed at the bar stock level.
5/ Continuous monitoring inspection.
7
