MIL-DTL-0060945E (AR)
Conformance inspection by classification of characteristics
PARAGRAPH
TITLE
DRAWING NUMBER
8866714
1
1
SHEET
OF
4.4.2.2
Projectile Assembly
NEXT HIGHER ASSEMBLY
8886326
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
REFERENCE
CRITICAL
None defined
MAJOR
101
Profile of rotating band
Level IV
3.2.2
Gage
102
Diameter of rotating bands
Level IV
3.2.2
Gage
103
Diameter of large groove
Level IV
3.2.2
Gage
104
Diameter of small groove
Level IV
3.2.2
Gage
Distance from nose to back of rotating
105
Level IV
3.2.2
Gage
band
Total run-out of rotating bands with
106
Level IV
3.2.2
Gage
bourrelet and body diameter
107
Total length (excluding cut-off nib)
Level IV
3.2.2
Gage
4.5.2, 4.5.2.1, Table
108
Push test of rotating band
80 1/
3.2.2
IV
MINOR
201
Marking missing
Level II
3.2.2
Visual
202
Evidence of poor workmanship
Level II
3.6
Visual
Notes:
1/ Accept on zero (0) and reject on one (1) or more failures.
