MIL-DTL-0060945E (AR)
TABLE II. First article quantity
DRAWINGS
QUANTITY
PART DESCRIPTION
Body
8866715
60
Projectile Assembly
8866714
100
4.3.2 Inspections to be performed. The first article inspection shall be 100% examination
of all drawing requirements including workmanship for the parts and assemblies listed and the
tests specified in Table III herein.
4.3.3 First Article rejection. If any item of the sample fails to comply with the First
Article requirements, the sample shall be rejected.
TABLE III. First article inspection
NO. SAMPLE
REQUIREMENT
INSPECTION
EXAMINATION OR TEST
UNITS
PARAGRAPH
METHOD
Body (Dwg. 8866715)
Examination for defects
50 1/
3.2.1
Gage
Salt spray
10
3.2.1.1
4.5.1
Projectile Assembly (Dwg.
8866714)
Examination for defects
50 1/
3.2.2
Gage
Push test of rotating band
50
3.2.2
4.5.2, 4.5.2.1,
Table IV
Notes:
1/ 25 samples shall be inspected for unlisted characteristics.
4.4 Conformance inspection.
4.4.1 Inspection lot formation. Lot formation shall be in accordance with MIL-STD-
1916. Each inspection lot of projectiles shall be produced with components complying with the
following constraints:
a. Metal parts or components from one lot interfix number, from one manufacturer.
4.4.1.1 Ammunition lot numbers. Ammunition lot numbers shall be assigned in
accordance with MIL-STD-1168. Visually verify that each lot is identified as the type, caliber,
model, and lot number in accordance with MIL-STD-1168.
