MIL-DTL-0060945E (AR)
Conformance inspection by classification of characteristics
PARAGRAPH
TITLE
DRAWING NUMBER
8866715
1
2
SHEET
OF
4.4.2.1
Body
NEXT HIGHER ASSEMBLY
8866714
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
REFERENCE
CRITICAL None defined
MAJOR
101
Diameter of rotating band surface (after
Level IV
3.2.1
Gage
knurl)
102
Spherical radius
Level IV
3.2.1
Gage
103
Location of basic diameter (excluding
Level IV
3.2.1
Gage
cut-off nib)
104
Run-out of indicated area on taper with
Level IV
3.2.1
Gage
body diameter
105
Body diameter
Level IV
3.2.1
Gage
106
Diameter between knurl
Level IV
3.2.1
Gage
107
Width of knurl crest
Level IV
3.2.1
Gage
108
Width of rotating band surface
Level IV
3.2.1
Gage
109
Length from back of rotating band
Level IV
3.2.1
Gage
surface to front end of nose
110
Location of bourrelet shoulder
Level IV
3.2.1
Gage
111
Diameter of bourrelet
Level IV
3.2.1
Gage
112
Diameter below bourrelet
Level IV
3.2.1
Gage
2 per 8 hr
113
3.2.1
4.5.1
Salt spray 1/
shift
114
Coating thickness
Level IV
3.3
4.5.3
MINOR
201
Protective coating with bare spot on
bottom or forward of rotating band
Level II
3.2.1
Visual
groove
202
Incorrect color
Level II
3.2.1
Visual
203
Evidence of poor workmanship
Level II
3.6
Visual
Notes:
1/ The production represented by the 8-hour shift sample shall be rejected upon non-conformance to the acceptance
criteria defined in MIL-A-8625 when salt spray tested in accordance with 4.5.1.
