MIL-DTL-0048684B
Table II. First Article Inspection
PARAGRAPH
TITLE
DRAWING NUMBER
See Below
1
1
SHEET
OF
Projectile and Components
NEXT HIGHER ASSEMBLY
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
EXAMINATION OR TEST
CRITERIA/QUANTITY
PARAGRAPH
REFERENCE
Cartridge, 40MM, M918 TP (Dwg. 9399372)
Functioning Tests
240
MK19 MOD III Single Shot
144
3.5
4.4.2.4, 4.5.8.1
TABLE III
MK19 MOD III Rapid Fire
96 1/
3.5
4.4.2.4, 4.5.8.2
Air Pressure
56
3.2
4.5.8.1
Pull Test
56
3.2
4.5.8.2
Notes:
1/ informational only
4.4 Conformance inspection.
4.4.1 Inspection lot formation. Lot formation shall be in accordance with MIL-
STD-1916. For the components identified below, each inspection lot cartridges shall be
produced with components complying with the following constraints:
a. M169 cartridge case loading assemblies metal parts from one interfix
number, from one manufacturer.
b. Primers from one lot number from one manufacturer.
c. Projectile assemblies from no more than two (2) consecutive lots from
one lot interfix number and from one manufacturer.
d. Propellant from one lot number from one manufacturer.
e. Only cartridges from one lot per ammunition belt shall be used. No
short belts permitted.
f. Links from one interfix lot number from one manufacturer.
g. Metal parts from one lot interfix number, from one manufacturer.
4.4.2 Classification of characteristics.
a. Sampling requirements. Inspection sampling requirements for Critical, Major
and Minor characteristics are defined in MIL-STD-1916. Unless specified otherwise,
Verification Level IV shall be used for all characteristics defined as Majors and
Verification Level II for all Minor characteristics; Critical characteristics shall be
addressed in accordance with MIL-STD-1916.
b. Conformance inspection. Conformance inspection shall be performed in
accordance with paragraph 4.4.2.1 through 4.4.2.8. For all conformance inspections the
same sample specimen may be used for all non-destructive examinations or tests.
6
