MIL-DTL-0048684B
Conformance Inspection
Classification of Characteristics
PARAGRAPH
TITLE
DRAWING NUMBER
9399374
1
1
SHEET
OF
4.4.2.4
Projectile Assembly
NEXT HIGHER ASSEMBLY
9399372
CONFORMANCE
REQUIREMENT
INSPECTION METHOD
CLASSIFICATION
EXAMINATION OR TEST
CRITERIA
PARAGRAPH
REFERENCE
CRITICAL
1.
X-Ray examination
1/
100%
3.4
4.5.5
MAJOR
101.
X-Ray examination
2/
100%
3.4
4.5.5
102.
O-ring missing from groove
Level IV
3.2
Visual/9399372
MINOR
201.
Evidence of poor workmanship
Level II
3.8
Visual/4.5.11
Notes:
1/ Critical Defect is defined as (for definitions see MIL-DTL-48669):
a. Rotor in armed or partially armed position
b. Detent missing
c. Setback spring missing
d. Setback pin missing or retracted
e. Pinion or verge assembly missing
f. Detent not engaged in teeth of sector gear
g. Setback pin not blocking rotor
h. Detent spring missing
2/ Major Defect is defined as (for definitions see MIL-DTL-48669):
a. Foreign material present.
10
