MIL-DTL-12235A (MR)
1.2.1.2 Class 2. Plate-proofing projectiles made from aluminum bar stock will be classified as
Class 2. The letter "A" will follow the type designation number to indicate that the projectile is
made from aluminum. See Table I for a summary of Classes and Types.
1.2.2 Types.
1.2.2.1 Type I. Proofing-projectiles -37 mm designated M1000.
1.2.2.2 Type II. Proofing-projectiles -57 mm designated M1001.
1.2.2.3 Type III. Proofing-projectiles -75 mm designated M1002.
1.2.2.4 Type IV. Proofing-projectiles -90 mm designated M1003.
1.2.2.5 Type V. Proofing-projectiles -105 mm designated M1004.
1.2.2.6 Type VI. Proofing-projectiles - 20 mm designated M1005.
TABLE I. Proofing-projectile `s designations.
Type II
Type III
Type IV
Type V
Type VI
Type I
SIZE:
37 mm
57 mm
75 mm
90 mm
105 mm
20 mm
M1000
M1001
M1002
M1003
M1004
M1005
Class 1 (Steel)
N/A
M1001A
M1002A
N/A
N/A
N/A
Class 2 (Aluminum)
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this
specification. This section does not include documents cited in other sections of this specification
or recommended for additional information or as examples. While every effort has been made to
ensure the completeness of this list, document users are cautioned that they must meet all
specified requirements of documents cited in sections 3, 4, or 5 of this specification, whether or
not they are listed.
Government documents.
2.2
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and
handbooks form a part of this document to the extent specified herein. Unless otherwise
specified, the issues of these documents are those cited in the solicitation or contract.
2
